The engine, transmission, vibrating roller and roller is placed on the machine frame walking. The frame is composed of steel plate and steel welded, simple manufacture. Walking roller and the vibrating roller with top silk outside spherical centripetal ball bearing, with the outer ring and bearing seat surface of 22211 bearing dimensions the bearing is spherical, the bearing can rotate a certain angle in the bearing race, self-aligning, automatic lubrication, when the bearing is not concentric seat left, right on a frame, used when this bearing self-aligning, make up the error brought by the manufacturing and assembly. Operating mechanism design vibrating roller operating handle, left, right two direction control handle.
2, the main technical parameters of the shape size: length * width * height of 4900mm * 1480mm * 850mm (length change with stand the wrong width (here is the paving width is 3.5m in length); total quality: 950kg; total power: 13kW; paving leveling speed: 0 ~ 11m/min; paving width:
3.5m, 4m, 4.5m.5m, 5.5m (can be customized according to 22211 bearing dimensions user needs paving machine with different width sizes). 3, the technical characteristics of the flattening machine is a new type of cement concrete paver paving machinery in our country, in the construction and construction method of the past and other paving machine, has the following characteristics: (1) to 3 roller continuous work before and after root arranged work for device of continuous work, paving levelling the smooth pavement.
(2) good effect of compacting roller vibrating shaft as before, because of its side side vibration, high speed strike concrete density, which can make the concrete surface and the bottom layer has higher, compaction effect is good, can pave low slump concrete, also can avoid the previous vacuum absorption process.
(3) walk by itself, good paving quality 2 walking roller flattening machine can make before, after the self realization. In use according to the need to repeatedly forward, backward and paving and leveling, so that the density and evenness to reach the ideal requirements. (4) convenient operation left, right steering control handle to control the flattening machine at work always and template direction consistent. Vibrating roller operating handle can control the vibrating roller gear, realize machine work and stop. In addition, the preparation of the handle are concentrated in the machine end, therefore, the machine forward and backward, and the suspension of only 1 person operation.
(5) the spreading width self spreading width of different pavement only need to replace the 3 rollers, the other parts are not needed to change, suitable for different width of pavement, improve the use efficiency of flattening machine. (6) the paving efficiency high spreading speed is 1TIN / rain, according to 5.5m, the effective width of paver paving thickness 12cm, two times forming calculation, paving efficiency can reach 145rn3 / h. (7) and strong adaptability to adapt to all concrete work surface, such as high grade highway, city road, Airport Road, in general, ramps, engineering, cement concrete pavement for wood formwork, steel template, both sides have spread are applicable. (8) the machine equipped with convenient transportation shift automatic loading Trailer designed specifically for it, loading and unloading is only 2 minutes. The boat lorry, tractor trailer, cars are running speed of 30km / h, optional, smooth operation, very convenient transportation shift. (9) with two kinds of models which is a kind of engine as a power source, will not have to meet the condition of power supply during the construction of the user; another kind is by motor as power source, power supply construction meets the conditions of the user.
